DENVER VERTIGO Vertical Glass Drilling, Milling & Polishing Center

Описание: DENVER VERTIGO Vertical Glass Drilling, Milling & Polishing Center - 2500 x 5000 mm
https://www.glassandwindowmachinery.c...

CNC controlled vertical machining center for high production fabrication of doors, shower cubicles, display cases, cupboard doors, furnishing items, household appliances, windows for industrial vehicles, and structural facades. Vertigo can perform boring, countersinking and milling operations on a sheet of glass and can also carry out grinding and polishing operations on the edge of the sheet. Ideal for machining Monolithic, Laminated and LOW-E glasses.

The machine features CNC control of the glass drilling programs and graphic visualization of the programs. This machine combines the bright finishing of a straight edger with the squaring accuracy of a double edger, the versatility of a CNC center and the chipless drilling of a twin-head boring machine.

The machining center concentrates into one single system the ability for: Cupwheel edging and polishing with fixed and variable angles, glass sheet squaring, double-head drilling, notch & cut-out routing, edging & polishing of shaped elements and arrising and corner trimming.

Specifications:
-Max. glass size: 2600 x 5000 mm (102" X 196")
-Min. glass size: 500 x 300 mm
-Max. workable edge length: 5500 mm
-Glass thickness: 3 - 40 mm
-Y-Axis speed: 40 m/Min (131 FPM)
-Feed speed: 25 m/Min (82 FPM)
-Max. spindle rotation: 12,000 RPM
-Max. drill: 80 mm (3-1/8"
-Tool magazine positions: 18 + 19
-Cupwheels unit: N. 10 - 1 corner trimming head
-Inclination: 5° - Left to right travel
-Automatic tool magazine for main electrospindle: 12 ISO 40 MAS BT cone attachment
-Automatic tool magazine for drilling electrospindle: 8 ISO 30 Din cone attachment
-Software: Advanced Cad Cam with .Dfx files format import

-Dimensions: 4840 x 16,680 x 5000 mm
-Weight: 10500 kG (27,500 Lbs)


NOTE: The machine is in very good operating condition and is ready for immediate delivery.
