ABRITES RH850/V850 Programmer Reading a VDO MQB Analogue Dashboard with RH850 processor R7F701407
Автор: AVDI FAN
Загружено: 2023-06-28
Просмотров: 11762
Описание:
Hello, friends!
Today I am going to show you how to use the ABRITES RH850/V850 Programmer to read Immo data from a VDO MQB Analogue dashboard with a locked RH850 processor R7F701407. The Immo data includes Power Class of the vehicle, VIN, Component Security bytes, Component Protection bytes, and more. This information can be used to perform tasks, such as key programming and module replacement.
As you may now, this Programmer for locked RH850/V850 processors brings revolutionary functionalities, unmatched on the market still. The procedure for reading the Immo data requires NO trace cutting, and NO pin lifting. It is significantly easier and limits the risk of you damaging the module you are working on.
What's most important when using the ABRITES RH850/V850 Programmer is to identify the module you are working on correctly, in order to discover the right wiring diagram. Follow the diagram strictly and nothing can go wrong. Make sure you unsolder the right capacitors and solder the Programmer's wires in the designated places on the PCB.
Watch the video for the step-by-step guide for this procedure. Leave a comment and a like, let me know how you like this upload. Subscribe and ring the bell for more tutorials!
Have fun,
AVDI FAN
Hardware used:
1. AVDI - https://abrites.me/avdi-zn085-1407-video
2. ABRITES RH850/V850 Programmer - https://abrites.me/rh850-zn085-1407-v...
Software used:
1. AMS - https://abrites.me/ams-zn085-1407-video
2. VN021 - https://abrites.me/vn021-zn085-1407-v...
