Replacing 78pin FPC Connector on Samsung A51 5G Motherboard for Data Recovery Project
Автор: Apple Pie Tech
Загружено: 2022-02-21
Просмотров: 9823
Описание:
Samsung Phone was smashed. Main FPC Connector was damaged so it had to be replaced. Used FPC Connector from Samsung S20 which is compatible with A51. Used Low Melt Solder in this project and Hot air to do Factory-like FPC replacement without damaging any components on the board.
Equipment and parts I use:
MG Chemicals Overcoat Pen https://amzn.to/34T7jow
Hakko FR810B-05 SMD Hot Air Rework Station: https://amzn.to/33Y4FNK
Hakko Air Rework Station Bent Nozzle Kit: https://amzn.to/3FOdPtl
JBC NASE-1C Nano Rework Station: https://amzn.to/3eKTKsB
Hakko FX951 Soldering Station: https://amzn.to/3JPVNdj
Hakko T15-BCM2 Concave Bevel Tip: https://amzn.to/3JSwLu1
Amtech NC-559-V2-TF Flux : https://amzn.to/3eGt9Nm
Low Melt Solder: https://s.click.aliexpress.com/e/_ACum5W
Mechanic Leaded Solder 63/37: https://s.click.aliexpress.com/e/_AeKk9i
Mechanic OK7 Glue: https://s.click.aliexpress.com/e/_A9Ujxr
