1- Ansys Electronics-Maxwell 2D-Electrostatic, Cylindrical Electrode System
Автор: Halil Ibrahim Uckol
Загружено: 2021-03-21
Просмотров: 8639
Описание: By using analytical calculation, we find that Emax= 28.85 kV/cm and Emin= 14.43 kV/cm for the cylindrical electrode system with the inner radius of 50 mm, the outer radius of 100 mm, and the voltage difference between the electrodes of 100 kV. The per-unit capacitance of the system is 80.26 pF/m.
