Low Cost Controller of BLDC motor.
Автор: Narrmiss
Загружено: 2012-03-28
Просмотров: 92040
Описание:
=== Added at 2017/08/27 ===
Please check this link. you can find schematic and source code similar my work.
https://github.com/bluerobotics/BlueESC
actually it is not perfectly same with mywork, but main circuit is same.
(my work has no temperature sensor and voltage sensor.
I/O port and half bridge are different.)
you CANNOT DO THIS WORK without understanding circuit and source code. especially about Back-EMF.
If you want to find making ESC step by step guide, DON'T DO THAT. it cannot be possible.
====
This work is done few years ago when I was graduate student.
now all schematics and source code is gone.
but I remember the schematic is same the basic one, you can search it on google with "esc schematic" key words
======= previous message =======
It is the ESC.
Electric Speed Controller of Sensorless BLDC motor.
I have soldered it myself.. and almost fine.
but there are some trouble in the startup code.
I will fix it, soon.
