BMW E39 M5 Park Distance Control (PDC) Retrofit DIY
Автор: E39Source
Загружено: 2018-12-03
Просмотров: 28963
Описание:
PARTS LIST:
Main Power Harness - 61120027006
Rear PDC Sensor Harness - 61126920858
Front PDC Sensor Harness - 61120027997
Front PDC Sensors (Black) x 4 - 66206989068
Rear PDC Sensors (Black) - 66206989069
PDC Module - 66209129816 (or any part number with 3 connectors)
PDC Module Bracket - 66218371300
PDC Module Bracket Nuts x 2 - 64507336307
Rear Gong Speaker - 66216903103
Gong Speaker Nut - 07129905817
Front Left Bumper Trim with PDC Holes - 51117894139
Front Right Bumper Trim with PDC Holes - 51117894140
Rear Left Bumper Trim with PDC Holes - 51122498501
Left Rear Bumper Trim with PDC Holes - 51122498502
Rear Bumper with PDC Holes - 51122498505
Diameter of inside of rear PDC holes - 2.2 cm
Distance from the center of the hole (center of the PDC sensor) to the body line - 1.8cm
Distance from the top of the outer hole to the bottom of the body line - 3.1cm.
End of body line to center of hole - 6.2cm
BMW PDC Retrofit Document - https://www.dropbox.com/s/61lfqftixxw...
E39Source website: http://www.e39source.com
Help support E39Source by donating: http://www.e39source.com/donate
